ZJ new vertical offset press

ModeZJ47IILNPMaximum printing area454×345mmMaximum size of Paper470×365mmPS Plate size470×380mmRubber plate size466*415*1.95mmPaper used28-255g/m2Feeding methodSuction, cross feedDampening methodMolton modeThe number of ink roller11 two-color head(3 form inking rollers)The number of dampening roller4 two-color head(2 form-damping rollers)Registering deviceWheel-type side pull guidePrinting speed2000-8000 pages/hourPower of main motor1.1KWPower of air-pump motor0.55KWPowerSingle-phase current 220V/50HZSize of the machine2180*935*1540mmWeight of the machine680kg ModeZJ56IILNPMaximum printing area550*375mmMaximum size of Paper560*400mmPS Plate size560*417*0.15mmRubber plate size560*460*1.95mmPaper used28-255g/m2Feeding methodSuction, cross feedThe number of ink roller11 two-color head (3 form inking rollers)The number of dampening roller4 two-color head (2 form-damping rollers)Registering deviceWheel-type side pull guidePrinting speed2000-8000 pages/hourPower of main motor1.1KWPower of air-pump motor0.55KWPowerSingle-phase current 220V/50HZSize of the machine2180*935*1540mmWeight of the machine740kg Application object: Suitable for schools, hospitals, small and medium-size printing enterprises and individual printing Paper used: 28-255g/m2 paper printing, such as typing paper, newsprint, kraft paper, Copperplate paper, especially for simple four-color overprinting and single-color printing, suitable for printing products’ NP, printing, indentation, impression line and also for s Main characteristics: 1.Accurate register 2.stable pressure, both thick paper and thin paper can be used, 3.Stable performance 4.Every part of the press is made precisely and gears are famous grinding gears of high density. . 5.NP, resin plates, indentation, printing and the dichromatic note with red can be finished once. Main function:The automation degree is high, all adoptions micro-computer controls, can complete the offset printing once, relief printing, beat the number (NP), press . New Ink-Supplying System: provide the system of ink more perfectly, the host adopts three ink two water, the biggest limit ground guaranteed the full version printing ink measures supply with the result of ink , guarantee the printing quality that complete the high accuracy. Open/close-type Number Unit:The numbering unit can be opened and closed as a whole within an angle of 120°. It can be opened when it is not being used. Its installment is also very easy Resin Relief Printing:Two form inking rollers are purposefully used in the inking system to conduct full page mono-color printing. This function has a broad scope of application in areas such as relief printing and color printing etc. Indentation:This machine has a drum-like cylinder with cross bore line. The cylinder can cut either vertical or horizontal creasing lines. The whole process is conducted quietly, stably and accurately.
